7222-8525-80

7222-8525-80

Store / SWP Connectors
£0.00
Sold out
Sold out
Product Details
Classified Parts Housing
Family SWP Connectors
Type -
Yazaki Part Number 7222-8525-80
Connection Type Wire to Wire
Unsealed/Sealed Sealed
Male/Female Male
Number of Poles 2
Tab Width mm(inches) 1.8(070)
Material PBT
Plating -
Colour Brown
Rating -
Mating Part Numbers 7123-8525-80
Product Specification No. YPES-11-04-012
Instruction Manual No. YPES-15-029
Product Specification
Allowable Current(Ref.) 9A(Ref)
Low Level Contact Resistance 3milli ohm Max.(Initial)
Insulation Resistance 100Megohm Min.(at 500VDC)
Withstanding Voltage 1000V AC (1min.)
Temperature Range -40 to 120deg.C
Application List of Installable Components
Terminals Wire Seals Holders
7114-1471 7157-7811-80 7157-7813-80
7114-1471-08 7157-7812
7114-1472 7157-7897-60
7114-1472-08 7157-7899-90
Show More
